IP65 960x960mm Curved Energy Saving LED Display Exterior Led Panels
Premium Products
IP65 960x960mm Curved Energy Saving LED Display Exterior Led Panels
1
2
3
Brand Name :EliteLED
Model Number :P6 P8 P10
Certification :CE
Place of Origin :Guangdong, China
MOQ :1sqm
Price :Negotiable
Supply Ability :3000sqm/month
Delivery Time :18 days
Packaging Details :Wooden cases or flight cases
Application :Outdoor Advertising Panel
Pixel Pitch :6mm, 8mm, 10mm
Brightness :6000nits
Product name :Curved Outdoor Led Screen
Cabinet size :960x960mm
LED chip :Nationstar, Kinglight
Control system :Nova
Certificate :CE
Warranty :2 Years
Contact Now
Outdoor Advertising LED Display Billboard Front Service Exterior LED Display
Energy Saving LED Billboard Features:
1. Front access, slim aluminum cabinet, easy and fast to install and maintenance.
2. 2.8V&3.8V energy saving design, no need air-conditioner, environmental and save cost.
3. Support 90 degree installation, seamless splicing at the corner.
4. Totally warterproof of front and back IP65.
5. Competitive price, you are welcome to contact us for a free project evaluation.
6. Curved screen adjustable, creative design to meet your requirement.
7. With Energy Saving technique, the power consumption reduce from 350W/Sqm to 150W/Sqm.
Model
P4
P5
P6
P8
P10
Pixel Pitch(mm)
4
5
6.67
8
10
LED Chips
SMD1921
SMD2525
SMD3535
SMD3535
SMD3535
Pixel density(dots/m2)
62500
40000
22477
15625
10000
Driving Method
1/10 scanning
1/8 scanning
1/6 scanning
1/5 scanning
1/2 scanning
Module Size(mm)
320*160
320*160
320*160
320*160
320*160
Module Resolution
80*40
64*32
48*24
40*20
32*16
Cabinet Size( W*L mm)
960*960
960*960
960*960
960*960
960*960
Cabinet Material
Magnesium
Alloy
Magnesium
Alloy
Magnesium
Alloy
Magnesium
Alloy
Magnesium
Alloy
Cabinet Weight( Kg/m2 )
35
35
35
35
35
Max.Consumption(W/m2)
800
800
800
800
800
Ave.Consumption(W/m2)
350
350
350
350
350
Brightness( Nits )
≥5500
≥5000
≥5500
≥5800
≥6000
Viewing Angle (Vertical / Horizontal)
120° / 120°
120° / 120°
120° / 120°
120° / 120°
120° / 120°
Refresh Rate
≥1920Hz
≥1920Hz
≥1920Hz
≥1920Hz
≥1920Hz
IP Level
IP65
IP65
IP65
IP65
IP65
About Us:
SHENZHEN ELITELED ELECTRONICS CO., LTD. is a leading LED display applications products and solutions provider, specialized in LED research and development, manufacturing. Sales and servic, dedicated to providing high-quality, high-performance LED applications and solutions for professional channel customers and end-users at home and abroad.
Our products have been widely used both at home and abroad. Since its foundation, we have become one of the best LED product and solution providers in the country through our unremitting efforts and have won the industry's highest recognition
The development of the company so far, the sales outlets throughout the country, the export products exported to more than 10 countries and regions, 3C, FCC, CE, IP65, IP67, IS9001, ROHS, and other qualifications, product testing reports, patent certificate.
FAQ:
Q1: Can the LED display screen work at corrosive gas environment?
A1: Please do not install the display in corrosive gas environment containing acid or base components, such as chemical warehouse.
Q2: Can the LED display screen work at electromagnetic radiation environment?
A2: Please do not install display when electromagnetic radiation and radio frequency radiation environment is over field strength 5V/m.
Q3: Can the LED display screen work when lightning?
A3: If necessary, users have to install surge switches in the distribution box and ground fault protection to avoid lightning strikes. Do not use the display in strong lightning and other severe weather.
Q4: How long can the LED display screen display?
A4: LED display at least rest 2 hours a day. Normally turn on the screen at least twice a week or more (Especially in the rainy season it is necessary to turn on the display every day). And it maintains more than 2 hours every time.
